AETQH Series Seawater Submersible Pump

Application:

It is suitable for offshore platform fire-fighting, thermal dissipation, seawater desalinization, seawater lifting, coastal square fountain, mari-culture and attemperation as ground source heat pump in coastal area. It can also lift underground drinking water and mineral water, etc.

Working Conditions:

The motor shall be submerged into water with the depth ≤ 70m, water temperature ≤ 20℃.

Solid contents (mass ratio): ≤0.01%;

Refer to the technical agreement to learn more parameters.

Materials:

AETQH Series stainless steel submersible pump has several kinds of material. Seawater and strongly corrosive medium: austenitic stainless steel 316, 316L, tin bronze, etc. Moderately corrosive medium: austenitic stainless steel 304, etc.

Advantages:

CNC lathe precision machining ensures parallelism and perpendicularity of all the castings. With rigorous testing, well installation and full load performance test, you can fell easy to use it. Some of our products manufactured by introducing the Germany Ritz technology. Improving the pump's efficiency and making it more energy-saving & environment-friendly.

Motor Parameter

The motor is in accordance with GB/T2818-2002 pump industry standard, and it is lubricated by water. The motor must be filled with water before operation. The standard length of the extended cable is 3m. If you have special requirement, we can extend the cable length. The working temperature shall be a bit higher than that of common motor because of its poor magnetic condictivity.

Power:

The general power specifications is 380V / 50Hz ±5. We can also provide the custom made specifications at your requests. The variation of voltage and frequency rated value and its influence on motor performance and temperature shall meet the requirements of GB755 (Chinese National Standard).

Notes:

We can provide you with the suitable products if the actual working condition, the voltage and the frequency are not meeting your operation requirements.
